Description
Siemens Inverter Drive, 0.37 kW, 0.55kW, 3 Phase, 400 V ac, 1.9 A, 2.3 A, SINAMICS G120C Series – NEW
Specifications
|
Desc
|
Value
|
|---|---|
| Power Rating | 0.37 kW, 0.55kW |
| Phase | 3 |
| Supply Voltage | 400 V ac |
| Current Rating | 1.9 A, 2.3 A |
| For Use With | AC Motors |
| Series | SINAMICS G120C |
| Field Bus Communication Type | Profinet |
| IP Rating | IP20 |
| Output Frequency | 0 → 240 (Vector Control) Hz, 0 → 550 (V/F Control) Hz |
| STO | Yes |
| Drive Type | Vector Control |
| Filter Included | Yes |
| Special Features | Sensorless Vector Control, Variable Frequency Eco Linear/Square-Law, Variable Frequency Linear/Square-Law/Parameterizable, Variable Frequency with Flux Current Control |
| Overall Length | 73mm |
| Standards Met | CE, C-Tick (RCM), cUL, EMC Directive 2004/108/EC, Low Voltage Directive 2006/95/EC, UL |
| Overall Width | 178mm |
| Interface | Ethernet/IP, PROFINET |
| Overall Depth | 173mm |
