Main Range of product Preventa Safety automation Product or component type Preventa safety module Safety module name XPSAXE Safety module application For emergency stop and switch monitoring Safety level Can reach PL e/category 4 conforming to EN/ISO 13849-1 Can reach SILCL 3 conforming to EN/IEC 62061 Safety reliability data DC > 99 % conforming to EN/ISO 13849-1 MTTFd = 457 years conforming to EN/ISO 13849-1 PFHd = 3E-8 1/h conforming to EN/IEC 62061 Connections – terminals Captive screw clamp terminals, removable terminal block, 2 x 0.5…2 x 1.5 mm² flexible with cable end, with double bezel Captive screw clamp terminals, removable terminal block, 1 x 0.2…1 x 2.5 mm² solid without cable end Captive screw clamp terminals, removable terminal block, 1 x 0.2…1 x 2.5 mm² flexible without cable end Captive screw clamp terminals, removable terminal block, 1 x 0.25…1 x 2.5 mm² flexible with cable end, without bezel Captive screw clamp terminals, removable terminal block, 1 x 0.25…1 x 1.5 mm² flexible with cable end, with bezel Captive screw clamp terminals, removable terminal block, 2 x 0.2…2 x 1 mm² solid without cable end Captive screw clamp terminals, removable terminal block, 2 x 0.2…2 x 1 mm² flexible without cable end Captive screw clamp terminals, removable terminal block, 2 x 0.25…2 x 1 mm² flexible with cable end, without bezel Output type Relay instantaneous opening, 3 NO circuit(s), volt-free Number of additional circuits 1 NC [Us] rated supply voltage 24 V DC – 15…10 % 24 V AC
